The SKIPPER GDS 101 is a navigation Echo Sounder with a large, high resolution colour LCD display. The Echo Sounder graphics are continuously shown on the LCD along with complete navigational details. External connectors are provided for printer, VGA and NMEA in/output.
The SKIPPER GDS 101 contains history memory, who stores depth, time and other available navigation data continuously in the last 24 hours. Information can also be printed out.
GDS 101 is prepared for connection of 1 transducer with a resonant frequency of 38, 50 or 200 kHz. A wide range of transducers are available to fit the vessels requirement.
All IMO requirements are met or exceeded. Comprehensive interfaces are available including NMEA 0183 inputs and outputs.
SPECIFICATIONS
Power Supply
AC: 115 - 230 V 50/60 Hz
DC: 20 - 32 V
Power Consumption
50 W at 24 V, 70 W at 230 V or 115 V
Display
10,4” color TFT
Mounting Dimensions
300 mm wide x 320 mm high
Printer
External printer, contact SKIPPER
Memory
More than 1 month depending on Compact Flash memory card
Ranges
Selectable from 0 - 10 m to 0 - 1600 m
Measuring Accuracy
Better than 1 %
Frequencies
Standard, 38, 50 and 200 kHz, selectable from keybord. (Other freq. on request)
